A breezy tour of reinforcement-learning experiments that started with “what if?” and ended with better-behaved intersections and delivery droids.
Why I suddenly cared about queues and collisions
Picture this: you’re running late, the light stubbornly stays red, and the only thing moving is your smartwatch’s heart-rate graph. Later, you order something online and—surprise!—it’s delayed because a warehouse robot got lost playing bumper-cars with a forklift.
Both headaches share a root cause: sequential decisions under uncertainty. That’s catnip for reinforcement learning (RL), so I built two toy worlds:
- Traffic-Light Town – one four-way intersection, cars arriving via Poisson magic, one light that can stay put or switch.
- Warehouse-World – a grid full of boxes, walls, equipment, roaming workers, and one slightly clumsy robot tasked with deliveries.
Each environment is an MDP (state, action, reward, transition, discount). Now we need agents.
Meet the squad (a.k.a. four ways to adult in an MDP)
| Persona |
Algorithm |
Elevator pitch |
| The Planner 🗺️ |
Value Iteration |
Looks ahead everywhere, scribbles values on a cosmic whiteboard, then acts. |
| The Iterative Boss 🧑💼 |
Policy Iteration |
“Here’s the plan… wait, let’s evaluate… okay new plan!”—fewer updates, beefier math. |
| The Adventurous Teen 🛹 |
Q-Learning |
Ignores the family plan, learns by trial and error, and still (eventually) finds optimality. |
| The Cautious Driver 🚗 |
SARSA |
Sticks to what it actually does, updating on-policy; smoother, safer, sometimes slower. |
All four share an ε-greedy “try-stuff-early, exploit-later” vibe, with exponential decay to keep wanderlust in check.
Experiment montage (what we tweaked and why)
Traffic-Light Town
E1 Baseline; E2 reward-shaping (bonuses for clearing queues, side-eye for congestion); E3 early-exit when intersection is empty; E4 balanced vs skewed traffic arrival rates.
Warehouse-World
E1 Baseline; E2 reward-shaping (Manhattan-distance candy, collision pain); E3 four flavours of start/goal randomness; E4 deterministic ➜ coin-toss action noise.
Same hyper-params unless noted: γ = 0.9, α = 0.1, episodes = 2 000.
What happened (highlights only—we spared you 40 000 plots)
Traffic results
- Reward shaping = green lights galore. Model-free agents stopped the dreaded “blink-blink-stall” pattern and actually kept queues short.
- Terminal on clearance made planners laser-focused on short-term wins; model-free lost some steam because episodes ended before long horizons paid off.
- Skewed arrivals (think Monday-morning commute) exposed model-free bias—over-serving the busy lane, starving the quiet one. Planners stayed balanced.
Warehouse results
- Distance-based treats turned Q-Learning into a speedy courier (≈ 3 boxes/episode) while SARSA chose the “slow-and-no-crash” lifestyle.
- Randomising the goal ballooned the state-space; SARSA froze, Q-Learning bumped into things—but extra training (10 k episodes) revived them.
- A pinch of randomness (80/20 action success) broke deterministic cycling and reduced time-outs; too much chaos (50/50) sent everyone back to square one.
Hyper-parameter heartbreak (& hope)
| Knob |
Low setting |
High setting |
Observed mood swing |
| γ (discount) |
0.5 |
0.9 |
Lower γ loved quick traffic fixes; higher γ needed for epic warehouse treks. |
| θ (planner convergence) |
1e-2 |
1e-10 |
Loose tolerance = faster but a bit sloppier value maps. |
| ε decay |
0.5 |
0.99 |
Fast decay calmed policies early; slow decay uncovered hidden corners. |
| Episodes |
5 000 |
10 000 |
Diminishing returns in Traffic-Town, but a lifesaver for lost robots. |
Moral: tune knobs per environment. One size never fits all—just like traffic lights in a warehouse would be silly.
Big take-aways (TL;DR)
- Planners shine when you know the rules and crave fast convergence—great for modest intersections.
- Model-free wins when the map is fuzzy or huge—robots bump into unknowns daily.
- Reward shaping is practically mentorship: give agents milestone pats on the back and they’ll learn faster (but don’t over-script them).
- A dash of stochasticity prevents loop-lock—too little = boring cycles, too much = chaos.
- Hyper-parameters are the secret sauce. Invest in a good taste-test upfront.
Future mischief
- Multi-intersection networks with coordinated lights (think agent gossip).
- Swarms of robots sharing Q-tables or gossiping via federated learning.
- Potential-based shaping to guarantee no-regret tweaks.
- Deep RL for pixel-rich simulations—traffic cams and warehouse CCTV, here we come.
Thanks for reading! If you’re now imagining courteous traffic and stress-free delivery bots, my work here is done. Feel free to reuse the code, tweak the hyper-params, or just brag at the next coffee break that you know why ε matters.
Happy learning—and may all your lights be green! 💚
Note: If the embedded PDF is not displayed properly or if you are viewing this on a mobile device, please click here to access the PDF directly.
